Features
· Broad measurement range
· Small measurement area
· Wide range of emissivity settings
· Automatic emissivity setting using contact-type probe
(For AR-6500 series only)
Specifications
|
Model |
AR-6500 |
AR-6501 |
AR-6500-H |
AR-6501-H |
R-100 |
R-150 |
R-160 |
|
CE Approval |
CE |
CE |
CE |
CE |
— |
— |
— |
|
Measurement Range |
-50 to 500°C |
0 to 1200°C |
-50 to 500°C |
0 to 1200°C |
|
Resolution |
0.1°C |
1°C |
1°C |
0.1°C |
1°C |
|
Laser aiming |
◯ |
◯ |
◯ |
◯ |
— |
◯ |
◯ |
|
Contact Mode |
◯ |
◯ |
◯ |
◯ |
— |
— |
— |
|
Measurement Accuracy |
Table1 |
Table2 |
Table1 |
Table2 |
|
Reference junction compensation accuracy |
±0.2°C at 25±10°C |
|
Temperature coefficient |
±0.01% of full scale °C |
|
Power supply |
Ni-Cd rechargeable battery (4AA) |
|
Battery life |
30 hours to (10 hours when laser is used continuously) |
|
Environmental
limit |
Operation : 0 to 40°C, 0 to 80%RH (Without Dew)
Storage : -20 to 50°C, 0 to 85%RH (Without Dew) |
|
Analog output Table3 |
— |
1mV / °C |
— |
1mV / °C |
— |
— |
— |
|
Weight |
App. 400g |
|
Accessories |
Manual, Soft case, Lens cap, Charger |
|
— |
Output cable |
— |
Output cable |
— |
— |
— |
Table 1
AR-6500, AR-6501, R-100, R-150
|
Non-Contact |
250 to 500°C |
± (0.8% of reading + 1digit) |
|
0 to 250°C |
± (2°C + 1digit) |
|
-50 to 0°C |
± (3°C + 1digit) |
|
Contact |
-50 to 500°C |
± (0.05% of reading + 0.1°C) ±1digt |
|
|
|
Table 2
AR-6500-H, AR-6501-H, R-160
|
Non-Contact |
600 to 1200°C |
± (0.5% of reading + 1digit) |
|
250 to 600°C |
± (3°C + 1digit) |
|
0 to 250°C |
± (4°C + 1digit) |
