| 4-Wire Earth Ground Resistance Tester Kit HHM-GRT300 |
|
HHM-GRT300
| • |
2, 3, and 4-Wire Testing
|
| • |
Large Dual Line LCD
|
| • |
Autoranging
|
| • |
Automatic I (Current) Spike Check
|
| • |
Automatic P (Potential) Spike Check
|
| • |
Test Hold Function for Easy Operation
|
| • |
Automatic Zero Adjustment
|
| • |
AC Earth Voltage
|
| • |
Data Hold and Auto Power Off
|
| • |
Overrange and Low Battery Indication
|
 |
The HHM-GRT300 4-wire earth resistance tester has been designed and tested according to the IEC Publication 348, safety requirements for Electronic Measuring Apparatus, EN 61010-1, EN 61326-1, EN 61557-1, EN 61557-5 and other safety standards.
SPECIFICATIONS (Please review Specs pdf for complete product features and specifications)
Measuring Ranges Earth Resistance:
0 to 2Ω, 0 to 20Ω, 0 to 200Ω, 0 to 2 KΩ
Earth Voltage: 0 to 300 Vac (40 to 500 Hz)
Accuracy Earth Resistance: ±(2% rdg + 3 dgt)
Earth Voltage: ±(2% rdg + 3 dgt)
Earth Resistance/Resolution:
0 to 2 Ω/0.01 Ω
0 to 20 Ω/0.1 Ω
0 to 200 Ω/1 Ω
0 to 2 KΩ/0.01 KΩ
Test Frequency: 820 Hz
Test Current: 2mA
Temperature and Humidity Operating:
0 to 50°C (32 to 122°F) 80% relative humidity
Storage: -10 to 60°C (14 to 140°F) 80% relative humidity
Power Source: 1.5V “AA” x 8 (included)
Dimensions: 250 L x 190 W x 110 mm D (9.84 x 7.5 x 4.33")
Weight: Approx. 1430 g (50.44 oz)(battery included)
Fuse: 0.1A/250V 5 x 20 mm
| | |
|
| |
|
